Cadre
CadreAluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated SeatclampCouleurBluesapphire´n´blueTailles disponiblesSize Split: 27.5: S // 29: M, L, XL
Suspensions
FourcheSR Suntour XCR36X 2CR Air, Tapered, 15x110mm, 120mmAmortisseurSR Suntour EdgeX R 185x52.5mm, Rebound Adjust, Trunnion MountEntretoises d’amortisseurTop: 54mm Trunnion Mount, Bottom: 22.2x8mm
Assistance Électrique
MoteurBosch Drive Unit Performance Line CX max. 120Nm (BDU38)BatterieBosch PowerTube 800CommandeBosch Purion 200 with Integrated DisplayChargeurBosch 2A
Transmission et freinage
FreinsShimano BR-MT420, Hydr. Disc Brake (203/203)CommandesShimano Deore SL-M6210-IR, Direct Attach, Single ClickDérailleur arrièreShimano Deore RD-M6200-SGS, ShadowPlus, 12-SpeedPédalierACID MTB Hybrid Pro, 38TGuide chaîneReverse Flip-Guide E-Chain Guide, Direct Mount, I-PlateCassetteShimano Deore CS-M6200, 10-51TChaîneKMC e12
Roues
RouesACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless ReadyPneusSchwalbe Smart Sam, Active, 2.6
Périphériques
CintreCUBE Rise Trail Bar 35PotenceCUBE Performance Stem E-MTB 35, FPI-LinkPoignéesACID Hybrid PerformSelleACID Venec EMTB Plus 145Tige de selleCUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mmJeu de directionAcros AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
Accessoires
PédalesACID PP MTB
Poids
Poids du vélo26,7 kgPoids maximum du cycliste120 kgPoids maximum en charge150 kg
